Pv array
pv-array
dresses asset:pv-array
— and nothing else. Appearance is invisible to the drawing set, so adding this changes no
plan, no section and no elevation.
- 10of 500 meshes
- 2slots
- 1finish
Drag to orbit · scroll to zoom
$surface
$frame
This definition leaves
$surface and $frame
open, and a look line fills them. Every combination is one body — same
geometry, same selector, same sheets — so the block below rewrites itself as you pick.
Only materials are slottable: a size would have to agree with the plan, so it stays on
the entity.
Paste this
Every part: the 2 materialdefs the body resolves to, then the definition. Copying the lookdef alone still compiles and still validates — it just renders grey.
{"t":"materialdef","id":"pack-envelope-pv","of":"paint","value":20,"accent":"#18304f","body":{"type":"MeshPhysicalMaterial","roughness":0.18,"clearcoat":0.48}}
{"t":"materialdef","id":"pal-steel","of":"steel","value":72}
{"t":"lookdef","id":"pv-array","for":"asset:pv-array","desc":"Tilted photovoltaic panel array on a lightweight support frame.","slots":{"surface":"pack-envelope-pv","frame":"pal-steel"},"preview":{"projection":"perspective","azimuth":-34,"elevation":20,"fov":28,"margin":1.01},"body":{"type":"Group","children":[{"type":"Mesh","material":"concrete","geometry":{"type":"RoundedBoxGeometry","width":0.62,"height":0.16,"depth":0.48,"radius":0.035,"segments":3},"position":[-1.25,0.08,-0.62]},{"type":"Mesh","material":"concrete","geometry":{"type":"RoundedBoxGeometry","width":0.62,"height":0.16,"depth":0.48,"radius":0.035,"segments":3},"position":[-1.25,0.08,0.62]},{"type":"Mesh","material":"concrete","geometry":{"type":"RoundedBoxGeometry","width":0.62,"height":0.16,"depth":0.48,"radius":0.035,"segments":3},"position":[1.25,0.08,-0.62]},{"type":"Mesh","material":"concrete","geometry":{"type":"RoundedBoxGeometry","width":0.62,"height":0.16,"depth":0.48,"radius":0.035,"segments":3},"position":[1.25,0.08,0.62]},{"type":"bimtex:Run","count":3,"from":[-1.13,0,0],"to":[1.13,0,0],"children":[{"type":"Mesh","material":"$frame","geometry":{"type":"RoundedBoxGeometry","width":1.12,"height":0.025,"depth":0.92,"radius":0.009,"segments":3},"position":[0,0.2,-0.44],"rotation":[-0.43,0,0]}]},{"type":"bimtex:Run","count":3,"from":[-1.13,0,0],"to":[1.13,0,0],"children":[{"type":"Mesh","material":"$surface","geometry":{"type":"RoundedBoxGeometry","width":1.06,"height":0.03,"depth":0.86,"radius":0.01,"segments":3},"position":[0,0.225,-0.44],"rotation":[-0.43,0,0]}]},{"type":"bimtex:Run","count":3,"from":[-1.13,0,0],"to":[1.13,0,0],"children":[{"type":"Mesh","material":"$frame","geometry":{"type":"RoundedBoxGeometry","width":1.12,"height":0.025,"depth":0.92,"radius":0.009,"segments":3},"position":[0,0.5599999999999999,0.44],"rotation":[-0.43,0,0]}]},{"type":"bimtex:Run","count":3,"from":[-1.13,0,0],"to":[1.13,0,0],"children":[{"type":"Mesh","material":"$surface","geometry":{"type":"RoundedBoxGeometry","width":1.06,"height":0.03,"depth":0.86,"radius":0.01,"segments":3},"position":[0,0.585,0.44],"rotation":[-0.43,0,0]}]},{"type":"bimtex:Run","count":2,"from":[-1.25,0,0],"to":[1.25,0,0],"children":[{"type":"Mesh","material":"$frame","geometry":{"type":"TubeGeometry","path":[[0,0.16,-0.65],[0,0.61,0.65]],"radius":0.026,"radialSegments":10,"tubularSegments":18}}]},{"type":"bimtex:Run","count":2,"from":[-1.25,0,0],"to":[1.25,0,0],"children":[{"type":"Mesh","material":"$frame","geometry":{"type":"TubeGeometry","path":[[0,0.16,0.65],[0,0.16,-0.65]],"radius":0.026,"radialSegments":10,"tubularSegments":18}}]}]}}Or take the whole pack, which brings every entry and every material at once:
cat packs/envelope.ndjson model.ndjson > dressed.ndjson
